Node IO stress

Node IO stress causes I/O stress on the Kubernetes node.

Use cases

• Node IO stress fault verifies the resilience of applications that share the disk resource for ephemeral or persistent storage during high disk I/O usage.
• It tests application resilience on replica evictions that occur due to I/O stress on the available disk space.
• It simulates slower disk operations by the application and noisy neighbour problems by hogging the disk bandwidth.
• It also verifies the disk performance on increasing I/O threads and varying I/O block sizes.
• It checks if the application functions under high disk latency conditions. when I/O traffic is very high and includes large I/O blocks, and when other services monopolize the I/O disks.

Permissions required

Below is a sample Kubernetes role that defines the permissions required to execute the fault.

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  namespace: hce
  name: node-io-stress
spec:
  definition:
    scope: Cluster
permissions:
  - apiGroups: [""]
    resources: ["pods"]
    verbs: ["create", "delete", "get", "list", "patch", "deletecollection", "update"]
  - apiGroups: [""]
    resources: ["events"]
    verbs: ["create", "get", "list", "patch", "update"]
  - apiGroups: [""]
    resources: ["chaosEngines", "chaosExperiments", "chaosResults"]
    verbs: ["create", "delete", "get", "list", "patch", "update"]
  - apiGroups: [""]
    resources: ["pods/log"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["pods/exec"]
    verbs: ["get", "list", "create"]
  - apiGroups: ["batch"]
    resources: ["jobs"]
    verbs: ["create", "delete", "get", "list", "deletecollection"]
  - apiGroups: [""]
    resources: ["nodes"]
    verbs: ["get", "list"]

Prerequisites

• Kubernetes > 1.16
• The target nodes should be in the ready state before and after injecting chaos.

Mandatory tunables

Tunable	Description	Notes
TARGET_NODES	Comma-separated list of nodes subject to node I/O stress.	For example, node-1,node-2. For more information, go to target nodes.
NODE_LABEL	It contains the node label that is used to filter the target nodes. It is mutually exclusive with the TARGET_NODES environment variable.	If both the environment variables are provided, TARGET_NODES takes precedence. For more information, go to node label.

Optional tunables

Tunable	Description	Notes
TOTAL_CHAOS_DURATION	Duration that you specify, through which chaos is injected into the target resource (in seconds).	Default: 120 s. For more information, go to duration of the chaos.
FILESYSTEM_UTILIZATION_PERCENTAGE	Specify the size as a percentage of free space on the file system.	Default: 10 %. For more information, go to file system utilization percentage.
FILESYSTEM_UTILIZATION_BYTES	Specify the size of the files used per worker (in GB). FILESYSTEM_UTILIZATION_PERCENTAGE and FILESYSTEM_UTILIZATION_BYTES are mutually exclusive.	If both are provided, FILESYSTEM_UTILIZATION_PERCENTAGE takes precedence. For more information, go to file system utilization bytes.
CPU	Number of cores of the CPU that will be used.	Default: 1. For more information, go to CPU cores.
NUMBER_OF_WORKERS	Number of I/O workers involved in I/O stress.	Default: 4. For more information, go to workers for stress.
VM_WORKERS	Number of VM workers involved in I/O stress.	Default: 1. For more information, go to workers for stress.
LIB_IMAGE	Image used to run the stress command.	Default: harness/chaos-go-runner:main-latest. For more information, go to image used by the helper pod.
RAMP_TIME	Period to wait before and after injecting chaos (in seconds).	For example, 30 s. For more information, go to ramp time.
NODES_AFFECTED_PERC	Percentage of the total nodes to target. It takes numeric values only.	Default: 0 (corresponds to 1 node). For more information, go to node affected percentage.
SEQUENCE	Sequence of chaos execution for multiple target pods.	Default: parallel. Supports serial sequence as well. For more information, go to sequence of chaos execution.

File system utilization percentage

Free space available on the node (in percentage). Tune it by using the FILESYSTEM_UTILIZATION_PERCENTAGE environment variable.

The following YAML snippet illustrates the use of this environment variable:

# stress the I/O of the targeted node with FILESYSTEM_UTILIZATION_PERCENTAGE of total free space
# it is mutually exclusive with the FILESYSTEM_UTILIZATION_BYTES.
# if both are provided then it will use FILESYSTEM_UTILIZATION_PERCENTAGE for stress
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: engine-nginx
spec:
  engineState: "active"
  annotationCheck: "false"
  chaosServiceAccount: litmus-admin
  experiments:
  - name: node-io-stress
    spec:
      components:
        env:
        # percentage of total free space of file system
        - name: FILESYSTEM_UTILIZATION_PERCENTAGE
          value: '10' # in percentage
        - name: TOTAL_CHAOS_DURATION
          VALUE: '60'

File system utilization bytes

Free space available on the node (in gigabytes). Tune it by using the FILESYSTEM_UTILIZATION_BYTES environment variable. It is mutually exclusive with the FILESYSTEM_UTILIZATION_PERCENTAGE environment variable. When both the values are provided, FILESYSTEM_UTILIZATION_PERCENTAGE takes precedence.

The following YAML snippet illustrates the use of this environment variable:

# stress the i/o of the targeted node with given FILESYSTEM_UTILIZATION_BYTES
# it is mutually exclusive with the FILESYSTEM_UTILIZATION_PERCENTAGE.
# if both are provided then it will use FILESYSTEM_UTILIZATION_PERCENTAGE for stress
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: engine-nginx
spec:
  engineState: "active"
  annotationCheck: "false"
  chaosServiceAccount: litmus-admin
  experiments:
  - name: node-io-stress
    spec:
      components:
        env:
        # file system to be stress in GB
        - name: FILESYSTEM_UTILIZATION_BYTES
          value: '500' # in GB
        - name: TOTAL_CHAOS_DURATION
          VALUE: '60'

Limit CPU utilization

CPU usage limit while the CPU undergoes I/O stress. Tune it by using the CPU environment variable.

The following YAML snippet illustrates the use of this environment variable:

# limit the CPU uses to the provided value while performing io stress
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: engine-nginx
spec:
  engineState: "active"
  annotationCheck: "false"
  chaosServiceAccount: litmus-admin
  experiments:
  - name: node-io-stress
    spec:
      components:
        env:
        # number of CPU cores to be stressed
        - name: CPU
          value: '1'
        - name: TOTAL_CHAOS_DURATION
          VALUE: '60'

Workers for stress

Number of I/O and VM workers for the stress. Tune it by using the NUMBER_OF_WORKERS and VM_WORKERS environment variables, respectively.

The following YAML snippet illustrates the use of this environment variable:

# define the workers count for the i/o and vm
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: engine-nginx
spec:
  engineState: "active"
  annotationCheck: "false"
  chaosServiceAccount: litmus-admin
  experiments:
  - name: node-io-stress
    spec:
      components:
        env:
        # total number of io workers involved in stress
        - name: NUMBER_OF_WORKERS
          value: '4'
          # total number of vm workers involved in stress
        - name: VM_WORKERS
          value: '1'
        - name: TOTAL_CHAOS_DURATION
          VALUE: '60'
